New CP3650 Series - Angle Grinders








Warning
This product can expose you to chemicals including lead, which is known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to http://www.P65warnings.ca.gov.
Technical Specifications
Speed
Free Speed
12000 rpm
Air consumption at free speed (Normo)
17.6 1/sNl
Noise & vibrations
Sound Power
101 dB(A)
Sound Pressure
90 dB(A)
Uncertainty vibration-K
6.9 ft/s²
Vibration
23 ft/s²
Design & Functions
Autobalancer
No
Guard max rotation
360 °
Guard positions
15
Main Material type
Aluminium, Composite over-sleeve
Output Spindle Thread
5/8-11 UNC
Rotative guard type
Pull and Turn
Spindle lock
Yes
Starting system
Safety lever
Swiveling guard
Keyless
Wheel/Disc diameter (in)
4-1/2
Wheel/Disc diameter (mm)
115
Air information
Air consumption at load (Normo)
29.8 1/sNl
Air inlet thread size (in)
3/8
Air inlet thread type
BSP
Max dynamic air working pressure
90 psi
Min hose diam (16 ft hose length)
0.5 in
Min hose diam (5 m hose length)
13 mm
Size & Weight
Height (H)
4.02 in
Length (L)
9.74 in
Width (W)
5.12 in
Side to Center
1.34 in
Weight
4.85 lb
Power & Battery
Max power
2.41 hp








CP3650-120AB45
6151607840
Dimensions 38 x 17 x 17 cm
Weight 2.81 kg
