The CP9113G Series, a 1/4' (6.35 mm) capacity die grinder with collet is an industrial maintenance and production tool for grinding, contouring, deburring, and cleaning applications. It delivers a powerful governed motor of 1 hp (750 W) and a free speed up to 25,000 rpm. Available in straight or extended housing collet spindle. custom.product.country_of_origin. custom.product.commodity_code

custom.product.specification.title

custom.imperialcustom.metric
Size & Weight
Length (L)
320 mm
Weight
1.62 kg
Speed
Free Speed
25000 rpm
Air consumption at free speed
17 l/s
Air information
Air consumption at load
15 l/s
Air inlet thread size (in)
3/8
Max dynamic air working pressure
6.3 bar
Min hose diam (16 ft hose length)
0.38 in
Min hose diam (5 m hose length)
13 mm
Noise & vibrations
Sound Power
93.5 dB(A)
Sound Pressure
82.5 dB(A)
Uncertainty vibration-K
1.1 m/s²
Tightening Strategies
Angle Type
Straight
Power
Max power
750 W
Design & Functions
Collet max capacity
1/4 (6.4mm)
Collet/Collet holder/Collet nut type
Erickson serie 200 type
Governor type
NA
Main Material type
Steel
Rotative inlet
No
Spindle lock
No
Starting system
Safety lever
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext
CP9113GES product.image.text.alttext

CP9113GES

6151602070

1/4"(6 Mm) pneumatic die grinder

custom.product.benefits

Machined steel housing for a robust construction.
Front exhaust to eliminate dust and to give better visibility
Up to 1 hp (750 W) industrial grade motor and 25,000 rpm for a perfect material removal result
