CP7748 Series - Impact Wrenches
Technical Specifications
Torque
Max working torque fwd
750 Nm
Max torque reverse
1300 Nm
Min working torque fwd
95 Nm
Torque limited
No
Air information
Air consumption at load
12 l/s
Air inlet thread size (in)
1/4
Max dynamic air working pressure
6.3 bar
Min hose diam (16 ft hose length)
0.38 in
Min hose diam (5 m hose length)
10 mm
Noise & vibrations
Sound Power
105.3 dB(A)
Sound Pressure
94.3 dB(A)
Uncertainty vibration-K
4.5 m/s²
Vibration (m/s²)
12
Vibration
12 m/s²
Speed
Free Speed
7000 rpm
Size & Weight
Height (H)
200 mm
Length (L)
175 mm
Width (W)
78 mm
Side to Center
39 mm
Weight
2 kg
Design & Functions
Blow per minute
1350
Body
Composite
Clutch housing
Aluminium
Clutch lubrication type
Grease
Handle type
Pistol
Impact mecanism
Twin hammer
Main Material type
Composite
Output drive size (in)
1/2
Output drive type
Sq
Output retainer type
Friction ring
Starting system
Trigger
CP7748
8941077481
Dimensions 24.1 x 21 x 10 cm
Weight 2.41 kg
