CP6728/38/48/68/78 Series - Impact Wrenches
Technical Specifications
Torque
Max working torque fwd
350 Nm
Max torque reverse
475 Nm
Min working torque fwd
110 Nm
Torque limited
No
Air information
Air inlet thread size (in)
1/4
Max dynamic air working pressure
6.3 bar
Min hose diam (16 ft hose length)
0.38 in
Min hose diam (5 m hose length)
10 mm
Noise & vibrations
Sound Power
100 dB(A)
Sound Pressure
89 dB(A)
Uncertainty vibration-K
1.9 m/s²
Vibration (m/s²)
5.2
Vibration
5.2 m/s²
Speed
Free Speed
11500 rpm
Air consumption at free speed
16 l/s
Size & Weight
Length (L)
175 mm
Side to Center
31 mm
Weight
1.7 kg
Design & Functions
Body
Composite
Clutch housing
Aluminium
Clutch lubrication type
Oil bath
Handle type
Pistol
Impact mecanism
Twin hammer
Main Material type
Composite
Output drive size (in)
3/8
Output drive type
Sq
Output retainer type
Friction ring
Starting system
Trigger
Suspension option
Included
CP6728-P05R
6151590550
Dimensions 21 x 21 x 7.5 cm
Weight 2.06 kg
