CP7748-2

Benefits

Most powerful tool on the market in its class: 922 ft.lbs – 1250 Nm of maximum real torque in reverseBest price to performance/durability ratioLightweight due to composite housing Contoured comfort grip handle instead of TPR injected in handleSmooth Forward / Reverse Switch on backSuited for all maintenance applications: Light vehicle tire changing, General maintenance on vehicles and MRO applications

Features

1/2" composite impact wrenchOne handed forward/reverseFull power in reverse: 922 ft. lb - 1250 Nm maximum real torque in reverse3 positions in forward: Low - 180 ft-lbs. / 245 Nm - Medium - 480 ft-lbs. / 650 Nm - High - 730 ft-lbs. / 990 NmAluminum clutch & back housingFriction ring socket retainerFull teasing triggerCurved to be more ergonomic, Smaller diameter to fit better in hand palm and to be optimum balancedHandle with Thermo-Plastic Rubber injected in housing for a durable and comfortable grip; Resistant to most chemicals used in workshopsTwin hammer mechanism360° swivel air inletComposite housing

CP7748 y CP7748-2 - Versión 2019 (Español) 1.4 MB, PDF
CP7748 and CP7748-2 leaflet - 2019 version (English) 1.2 MB, PDF

	Metric	Imperial
Modelo	CP7748-2
Referencia	8941077486
Altura	200 mm	7.87 "
Ancho	78 mm	3 "
Consumo de aire real	12 l/s	25 cfm
Consumo promedio de aire	3 l/s	6.2 cfm
Directivas europeas	2006/42/EC (17/05/2006)
Distancia min centro al centro	39 mm	1 1/2 "
Estandares europeos	EN ISO 11148-6:2013
Forward_ms2	1.99 m/s²
Golpes por minuto	1350
Longitud	225 mm	8.86 "
Maximo Torque (en reversa)	1300 Nm	960 ft.lbs
Min. Tamaño de la manguera	10 mm	3/8 "
Nivel de ruido	94.3 db(A)
Peso neto	2.11 kg	4.65 lb
Potencia de sonido	105.3 db(A)
Rango del trabajo de torque (fwd)	95 - 750 Nm	70 - 555 ft.lbs
Socket retenedor	anillo de fricción
Tamaño de la rosca de entrada de aire	1/4 "
Vibración	11.3 m/s²
Vibración (adelante)	6.49 m/s²
Vibración - ISO	ISO 28927-2
Vibración K	3.8 m/s²
dimensiones de la caja	95x215x275 mm	3.75x8.45x10.85 "
sonido europeo estandar	ISO 15744
sonido incierto	3 db(A)
tipo de embrague	Twin Hammer
tipo de mango	Pistola
unidad de cuadro	1/2 "
velocidad libre	7000 rpm
